RH-DR HYDRAULIC RETRIEVABLE PACKER

The RH-DR hydraulic-set retrievable packer combines the pressure and Temperature ratings and reliability of a permanent packer with the convenience of a retrievable packer. At the same time, The RH-DR packer adds a function of drop-ball to release. The innovation design makes RH-DR packers have more extensive USES and lower operating costs.

Features

• Barrel slip design to minimize the pressure on casing

• Metal-to-metal backup shoes with 360° casing wall contact for element containment and reliability

• Slips located below element package for protection from debris

• No-mandrel movement operation

• Premium metallurgy and elastomers

• Drop-ball to release

Other sizes, connections, material and rubber options available upon request.
